CHEMI-CON 1800μF Aluminium Electrolytic Capacitor 250V dc, Snap-In - EKMQ251VSN182MA50S
- RS Stock No.:
- 841-4823
- Mfr. Part No.:
- EKMQ251VSN182MA50S
- Brand:
- CHEMI-CON
Bulk discount available
Subtotal (1 unit)*
£8.52
(exc. VAT)
£10.22
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 345 unit(s) shipping from 27 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £8.52 |
| 5 - 9 | £7.67 |
| 10 - 24 | £7.24 |
| 25 - 49 | £6.81 |
| 50 + | £6.39 |
*price indicative
- RS Stock No.:
- 841-4823
- Mfr. Part No.:
- EKMQ251VSN182MA50S
- Brand:
- CHEMI-CON
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Capacitance | 1800µF | |
| Voltage | 250V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 35 (Dia.) x 50mm | |
| Length | 50mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 35mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 2000h | |
| Lead Pitch | 10mm | |
| Ripple Current | 2.7Arms | |
| Series | KMQ | |
| Leakage Current | ≤ 3 CV μA | |
| Tolerance | ±20% | |
Select all | ||
|---|---|---|
Brand CHEMI-CON | ||
Capacitance 1800µF | ||
Voltage 250V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 35 (Dia.) x 50mm | ||
Length 50mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 35mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 2000h | ||
Lead Pitch 10mm | ||
Ripple Current 2.7Arms | ||
Series KMQ | ||
Leakage Current ≤ 3 CV μA | ||
Tolerance ±20% | ||
KMQ Series Snap-In Aluminium Electrolytic Capacitors
KMQ series aluminium electrolytic capacitors with a large capacitance of up to 2200μF and down-sized snap-in terminals. These KMQ aluminium electrolytic capacitors can operate up to 2000 hours @ 105°C and are non solvent resistant.
