Wurth Elektronik 100μF Aluminium Electrolytic Capacitor 35V dc, Radial, Through Hole - 860080574007
- RS Stock No.:
- 840-0411
- Mfr. Part No.:
- 860080574007
- Brand:
- Wurth Elektronik
275 In stock - FREE next working day delivery available
Added
Price Each (In a Bag of 25)
£0.212
(exc. VAT)
£0.254
(inc. VAT)
| Units | Per unit | Per Bag* |
| 25 - 100 | £0.212 | £5.30 |
| 125 - 225 | £0.156 | £3.90 |
| 250 + | £0.138 | £3.45 |
| *price indicative | ||
- RS Stock No.:
- 840-0411
- Mfr. Part No.:
- 860080574007
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
Wurth Elektronik Low Impedance WCAP-ATLI Capacitor Series, 1μF - 270μF
WCAP- ATLI are Low Impedance Aluminium Electrolytic Capacitor Series
Load life: 2000h – 5000h @ +105°C
Operating temperature: -55°C to +105°C
Wave soldering recommended
Load life: 2000h – 5000h @ +105°C
Operating temperature: -55°C to +105°C
Wave soldering recommended
Specifications
Attribute | Value |
|---|---|
| Capacitance | 100µF |
| Voltage | 35V dc |
| Mounting Type | Radial, Through Hole |
| Technology | Aluminium Electrolytic |
| Dimensions | 8 (Dia.) x 11.5mm |
| Height | 11.5mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 3000h |
| Lead Pitch | 3.5mm |
| Tolerance | ±20% |
| Series | WCAP-ATLI |
| Leakage Current | 35 μA |
| Ripple Current | 560mA |
| Dissipation Factor | 9 |
