Wurth Elektronik 100μF Aluminium Electrolytic Capacitor 10V dc, Surface Mount - 865250249006
- RS Stock No.:
- 839-5202
- Mfr. Part No.:
- 865250249006
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 pack of 5 units)*
£3.00
(exc. VAT)
£3.60
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 22 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 20 | £0.60 | £3.00 |
| 25 - 45 | £0.568 | £2.84 |
| 50 - 95 | £0.502 | £2.51 |
| 100 - 495 | £0.432 | £2.16 |
| 500 + | £0.336 | £1.68 |
*price indicative
- RS Stock No.:
- 839-5202
- Mfr. Part No.:
- 865250249006
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Capacitance | 100µF | |
| Voltage | 10V dc | |
| Mounting Type | Surface Mount | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 6.5 (Dia.) x 7.85mm | |
| Height | 7.85mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 6.5mm | |
| Maximum Operating Temperature | +85°C | |
| Lead Pitch | 2.3mm | |
| Lifetime | 2000h | |
| Tolerance | ±20% | |
| Ripple Current | 80mA | |
| Series | WCAP-ASNP | |
| Leakage Current | 50 μA | |
| Polarised | Polar | |
| Dissipation Factor | 20 | |
Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Capacitance 100µF | ||
Voltage 10V dc | ||
Mounting Type Surface Mount | ||
Technology Aluminium Electrolytic | ||
Dimensions 6.5 (Dia.) x 7.85mm | ||
Height 7.85mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 6.5mm | ||
Maximum Operating Temperature +85°C | ||
Lead Pitch 2.3mm | ||
Lifetime 2000h | ||
Tolerance ±20% | ||
Ripple Current 80mA | ||
Series WCAP-ASNP | ||
Leakage Current 50 μA | ||
Polarised Polar | ||
Dissipation Factor 20 | ||
Wurth Elektronik SMD Non-Polar WCAP-ASNP Series Capacitors
WCAP-ASNP are non-polarised Aluminium Electrolytic Capacitor Series
Features and Benefits
• Load life: 2000 h @ +85°C
• Operating temperature: -40°C to +85°C
• Reflow soldering recommended
• Operating temperature: -40°C to +85°C
• Reflow soldering recommended
