Wurth Elektronik 47μF Aluminium Electrolytic Capacitor 35V dc, Surface Mount - 865080543009
- RS Stock No.:
- 839-2051P
- Mfr. Part No.:
- 865080543009
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal 125 units (supplied on a reel)*. Quantities below 150 on continuous strip
£19.50
(exc. VAT)
£23.375
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 925 unit(s) ready to ship
- Plus 500 unit(s) shipping from 15 December 2025
- Plus 2,625 unit(s) shipping from 26 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 125 - 225 | £0.156 |
| 250 - 475 | £0.138 |
| 500 - 2475 | £0.129 |
| 2500 + | £0.122 |
*price indicative
- RS Stock No.:
- 839-2051P
- Mfr. Part No.:
- 865080543009
- Brand:
- Wurth Elektronik
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Capacitance | 47µF | |
| Voltage | 35V dc | |
| Mounting Type | Surface Mount | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 6.3 (Dia.) x 5.35mm | |
| Height | 5.35mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 6.3mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 2.2mm | |
| Lifetime | 2000h | |
| Leakage Current | 16.45 μA | |
| Polarised | Polar | |
| Ripple Current | 240mA | |
| Series | WCAP-ASLI | |
| Tolerance | ±20% | |
| Dissipation Factor | 14 | |
