Cornell-Dubilier 1000μF Aluminium Electrolytic Capacitor 100V dc, Snap-In - SLP102M100C1P3
- RS Stock No.:
- 744-1262
- Mfr. Part No.:
- SLP102M100C1P3
- Brand:
- Cornell-Dubilier
Bulk discount available
Subtotal (1 unit)*
£3.45
(exc. VAT)
£4.14
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- Final 14 unit(s), ready to ship from another location
Units | Per unit |
---|---|
1 - 9 | £3.45 |
10 - 49 | £2.75 |
50 - 99 | £2.62 |
100 + | £2.00 |
*price indicative
- RS Stock No.:
- 744-1262
- Mfr. Part No.:
- SLP102M100C1P3
- Brand:
- Cornell-Dubilier
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Cornell-Dubilier | |
Capacitance | 1000µF | |
Voltage | 100V dc | |
Mounting Type | Snap-In | |
Technology | Aluminium Electrolytic | |
Dimensions | 25 (Dia.) x 25mm | |
Height | 25mm | |
Minimum Operating Temperature | -40°C | |
Diameter | 25mm | |
Maximum Operating Temperature | +105°C | |
Lifetime | 3000h | |
Lead Pitch | 10mm | |
Series | SLP | |
Equivalent Series Resistance | 199mΩ | |
Tolerance | ±20% | |
Leakage Current | <=3√CV μA @ 5 min | |
Ripple Current | 1.81A | |
Select all | ||
---|---|---|
Brand Cornell-Dubilier | ||
Capacitance 1000µF | ||
Voltage 100V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 25 (Dia.) x 25mm | ||
Height 25mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 25mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 3000h | ||
Lead Pitch 10mm | ||
Series SLP | ||
Equivalent Series Resistance 199mΩ | ||
Tolerance ±20% | ||
Leakage Current <=3√CV μA @ 5 min | ||
Ripple Current 1.81A | ||
- COO (Country of Origin):
- CN
SLP series
3000 h ripple load life at rated voltage
Small case size with high capacitance
Suitable for switching power supplies
10 mm lead spacing
High ripple current
Small case size with high capacitance
Suitable for switching power supplies
10 mm lead spacing
High ripple current
