KEMET 470μF Aluminium Electrolytic Capacitor 400V dc, Snap-In - PEH536VDG3470M3
- RS Stock No.:
- 434-0942P
- Mfr. Part No.:
- PEH536VDG3470M3
- Brand:
- KEMET
Bulk discount available
Subtotal 10 units (supplied in a bag)*
£73.40
(exc. VAT)
£88.10
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 249 unit(s) shipping from 13 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 10 - 24 | £7.34 |
| 25 - 49 | £6.71 |
| 50 - 99 | £6.24 |
| 100 + | £5.70 |
*price indicative
- RS Stock No.:
- 434-0942P
- Mfr. Part No.:
- PEH536VDG3470M3
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KEMET | |
| Capacitance | 470µF | |
| Voltage | 400V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 35 x 50mm | |
| Height | 50mm | |
| Length | 50mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 35mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 4600 h @ +105 °C/400V dc/Ir, 6000h @ +105 °C/400V dc | |
| Polarised | Polar | |
| Ripple Current | 1.9A | |
| Series | PEH536 | |
| Tolerance | ±20% | |
| Equivalent Series Resistance | 190mΩ | |
| Leakage Current | 0.03 mA | |
Select all | ||
|---|---|---|
Brand KEMET | ||
Capacitance 470µF | ||
Voltage 400V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 35 x 50mm | ||
Height 50mm | ||
Length 50mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 35mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 4600 h @ +105 °C/400V dc/Ir, 6000h @ +105 °C/400V dc | ||
Polarised Polar | ||
Ripple Current 1.9A | ||
Series PEH536 | ||
Tolerance ±20% | ||
Equivalent Series Resistance 190mΩ | ||
Leakage Current 0.03 mA | ||
PEH536 Series
Long Life, snap-in electrolytic capacitor designed to offer high ripple current
For use in SMPS, electric drives, welding, UPS and other power electronic applications
Low equivalent series resistance (ESR)
6000 Hrs (105 °C); 4 Years (+40 °C)
For use in SMPS, electric drives, welding, UPS and other power electronic applications
Low equivalent series resistance (ESR)
6000 Hrs (105 °C); 4 Years (+40 °C)
Standards
IEC 384-4 long life grade 40/105/56
