RS PRO 100μF Aluminium Electrolytic Capacitor 35V dc, Surface Mount
- RS Stock No.:
- 276-6116
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 pack of 25 units)*
£8.275
(exc. VAT)
£9.925
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2,175 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
25 - 75 | £0.331 | £8.28 |
100 - 225 | £0.298 | £7.45 |
250 - 475 | £0.268 | £6.70 |
500 + | £0.241 | £6.03 |
*price indicative
- RS Stock No.:
- 276-6116
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Capacitance | 100µF | |
Voltage | 35V dc | |
Mounting Type | Surface Mount | |
Technology | Aluminium Electrolytic | |
Dimensions | 7.7 x 6.3mm | |
Height | 6.6mm | |
Length | 7.7mm | |
Minimum Operating Temperature | -40°C | |
Diameter | 6.3mm | |
Lifetime Max Temperature | 2000h | |
Maximum Operating Temperature | 105°C | |
Lifetime | 2000h | |
Tolerance | 20% | |
Ripple Current | 100mA | |
Leakage Current | ≦0.01 CV or 3 μA @ 1 min | |
Dissipation Factor | 14% | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Capacitance 100µF | ||
Voltage 35V dc | ||
Mounting Type Surface Mount | ||
Technology Aluminium Electrolytic | ||
Dimensions 7.7 x 6.3mm | ||
Height 6.6mm | ||
Length 7.7mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 6.3mm | ||
Lifetime Max Temperature 2000h | ||
Maximum Operating Temperature 105°C | ||
Lifetime 2000h | ||
Tolerance 20% | ||
Ripple Current 100mA | ||
Leakage Current ≦0.01 CV or 3 μA @ 1 min | ||
Dissipation Factor 14% | ||
- COO (Country of Origin):
- TW
RS PRO 100UF Surface Mount Electrolytic Capacitor, 35V (7.7 x 6.3mm)
A consistent and reliable encapsulated surface mount capacitor (SMD) designed for general purpose applications and well suited for use in communications and power supply equipment.
A 7.7 x 6.3mm Aluminium capacitor capable of up to 2000 hours of operation at full temperature and constructed with a safety vent design to release any build up of pressure preventing capacitor rupture.
The SMD Aluminium capacitors are supplied on a reel and are suitable for temperature extremes of -40 to +105℃.
Features and Benefits
Electrolytic capacitor
Surface mount
Safety vent design
2000 hours of operation at full temperature
7.7 x 6.3mm in size
Temperature range of -40 to +105℃
Standards and Approvals: IEC 60384-4
