CHEMI-CON 100 μF Capacitor 250V dc, Radial, Through Hole Radial Lead
- RS Stock No.:
- 251-4880
- Mfr. Part No.:
- EGXF251ELL101MK40S
- Brand:
- CHEMI-CON
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£1.66
(exc. VAT)
£1.99
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 420 unit(s) shipping from 17 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 49 | £1.66 |
| 50 - 99 | £1.44 |
| 100 - 199 | £1.21 |
| 200 + | £0.94 |
*price indicative
- RS Stock No.:
- 251-4880
- Mfr. Part No.:
- EGXF251ELL101MK40S
- Brand:
- CHEMI-CON
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Capacitance | 100μF | |
| Product Type | Capacitor | |
| Voltage | 250V dc | |
| Mount Type | Radial, Through Hole | |
| Length | 40mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 12.5mm | |
| Termination Type | Radial Lead | |
| Pin Count | 2 | |
| Capacitor Ripple Current | 2.2mA | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | RoHS II | |
| Automotive Standard | AEC-Q200 | |
| Series | GXF | |
| Tolerance | ±20 % | |
| Dissipation Factor | 0.15% | |
| Select all | ||
|---|---|---|
Brand CHEMI-CON | ||
Capacitance 100μF | ||
Product Type Capacitor | ||
Voltage 250V dc | ||
Mount Type Radial, Through Hole | ||
Length 40mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 12.5mm | ||
Termination Type Radial Lead | ||
Pin Count 2 | ||
Capacitor Ripple Current 2.2mA | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals RoHS II | ||
Automotive Standard AEC-Q200 | ||
Series GXF | ||
Tolerance ±20 % | ||
Dissipation Factor 0.15% | ||
- COO (Country of Origin):
- JP
The Nippon Chemi-Con Aluminium capacitor GXF series offers downsizing and high-ripple current. United Chemi-Con GXF High Ripple Aluminium Capacitor Leaded 100uF 250V. This series is compact, high-ripple current version of the GXE series. Used in automobile modules and networking equipment and other high temperature applications.
Endurance with ripple current 3,000 hours at 125°C
Solvent resistant type except 160 to 400Vdc
RoHS2 Compliant
Operating temperature range is from -40 to +125°C
Rated voltage range is from 25 to 400Vdc
