Nichicon 4.7μF Aluminium Electrolytic Capacitor 400V dc, Radial, Through Hole - ULD2G4R7MPD1TD

View all Aluminium Capacitors
Bulk discount available

Subtotal (1 tape of 500 units)*

£138.00

(exc. VAT)

£165.50

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 02 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Tape*
500 - 500£0.276£138.00
1000 - 2000£0.242£121.00
2500 - 4500£0.215£107.50
5000 +£0.208£104.00

*price indicative

RS Stock No.:
222-9611
Mfr. Part No.:
ULD2G4R7MPD1TD
Brand:
Nichicon
Find similar products by selecting one or more attributes.
Select all

Brand

Nichicon

Capacitance

4.7µF

Voltage

400V dc

Mounting Type

Radial, Through Hole

Technology

Aluminium Electrolytic

Dimensions

10 (Dia.) x 12.5mm

Length

12.5mm

Diameter

10mm

Maximum Operating Temperature

+105°C

Lead Pitch

5mm

Series

ULD

Nichicon LD Series


Nichicon LD Series Aluminium Electrolytic Capacitor an extremely long load life of 12,000 to 20,000 hours at 105ºC. The LD series capacitors offer a high temperature range, high voltage, low impedance and high ripple current. This series is ideal for use in the power supply for LED lighting.

High reliability
High ripple current
Long life up to 20,000 hours

The Nichicon ULD series is a Miniature sized aluminium electrolytic capacitor which has rated capacitance of 4.7 μF with capacitance tolerance of ± 20%. It is a long life product withstanding life of 10000 to 20000 hours at +105°C.

Compliant to the RoHS directive.
Miniature Sized, Long Life Assurance.
Suited for the power supply for LED lighting.
