Vishay 3300μF Electrolytic Capacitor 500V dc, Screw Mount - MAL250139332E3
- RS Stock No.:
- 187-6500
- Mfr. Part No.:
- MAL250139332E3
- Brand:
- Vishay
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 187-6500
- Mfr. Part No.:
- MAL250139332E3
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Capacitance | 3300µF | |
| Voltage | 500V dc | |
| Mounting Type | Screw Mount | |
| Technology | Electrolytic | |
| Dimensions | 76.4 Dia. x 105.8mm | |
| Height | 105.8mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 76.4mm | |
| Maximum Operating Temperature | +85°C | |
| Lifetime | 5000h | |
| Lead Pitch | 31.8mm | |
| Series | 501 | |
| Tolerance | ±20% | |
| Equivalent Series Resistance | 73mΩ | |
| Leakage Current | 3.3 mA | |
| Ripple Current | 12.6A | |
| Polarised | Polar | |
Select all | ||
|---|---|---|
Brand Vishay | ||
Capacitance 3300µF | ||
Voltage 500V dc | ||
Mounting Type Screw Mount | ||
Technology Electrolytic | ||
Dimensions 76.4 Dia. x 105.8mm | ||
Height 105.8mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 76.4mm | ||
Maximum Operating Temperature +85°C | ||
Lifetime 5000h | ||
Lead Pitch 31.8mm | ||
Series 501 | ||
Tolerance ±20% | ||
Equivalent Series Resistance 73mΩ | ||
Leakage Current 3.3 mA | ||
Ripple Current 12.6A | ||
Polarised Polar | ||
Aluminium Capacitors, Power General Purpose Miniaturized Screw Terminal
Useful life: 5000 h at +85 °C
Efficient design
Available in case sizes up to Ø 90 mm x 195 mm
APPLICATIONS
UPS
Energy storage in medical or industrial pulse systems
Solar inverters
Efficient design
Available in case sizes up to Ø 90 mm x 195 mm
APPLICATIONS
UPS
Energy storage in medical or industrial pulse systems
Solar inverters
