RS PRO 1000μF Electrolytic Capacitor 35V dc, Through Hole

View all Aluminium Capacitors
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
181-5432
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Capacitance

1000µF

Voltage

35V dc

Mounting Type

Through Hole

Technology

Electrolytic

Dimensions

13 Dia. x 21mm

Height

21mm

Minimum Operating Temperature

-40°C

Diameter

13mm

Maximum Operating Temperature

+105°C

Lifetime

1000h

Lead Pitch

5mm

Ripple Current

1.65A

Leakage Current

3 μA

Tolerance

±20%

Dissipation Factor

12%

COO (Country of Origin):
TW

RS PRO Electrolytic Capacitor


The RS PRO 1000μF through-hole mount electrolytic capacitor has a voltage rating of 35VDC and leakage current of 3μA. This low impedance capacitor has dimensions of 13mm x 21mm (diameter x length). This capacitor is designed with a safety vent construction.

Features and Benefits


• Tolerance: ±20%
• Lifetime: 1000 hours
• Ripple current: 1650mA
• Dissipation factor: 12%
• Lead pitch: 5mm
• Impedance: 0.037ohm
• Operating temperature ranging between -40°C and 105°C

Applications


• Motherboard
• Computer peripheral

Certifications


• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
