RS PRO 10μF Electrolytic Capacitor 63V dc, Through Hole

View all Aluminium Capacitors
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
181-5424
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Capacitance

10µF

Voltage

63V dc

Mounting Type

Through Hole

Technology

Electrolytic

Dimensions

5 Dia. x 11mm

Height

11mm

Minimum Operating Temperature

-40°C

Diameter

5mm

Maximum Operating Temperature

+105°C

Lifetime

1000h

Lead Pitch

2mm

Tolerance

±20%

Leakage Current

3 μA

Ripple Current

118mA

Dissipation Factor

9%

COO (Country of Origin):
TW

RS PRO Electrolytic Capacitor


The RS PRO electrolytic capacitor has a safety vent design with through-hole mounting and features a capacitance of 10μF, at a rated voltage of 63VDC. The RS PRO capacitor has a lifetime of 1000 hours and tolerance is ±20%.

Features and Benefits


• Diameter is 5mm
• Dissipation factor is 10%
• Height is 11mm
• Lead pitch is 2mm
• Leakage current is 3μA
• Operating temperature ranging between -40°C and 105°C
• Ripple current is 100mA
• Working voltage is 63VDC

Applications


• Computer peripheral
• Mother board

Certifications


• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
