RS PRO 220μF Aluminium Electrolytic Capacitor 10V dc, Radial, Through Hole
- RS Stock No.:
- 181-5380
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 pack of 100 units)*
£5.90
(exc. VAT)
£7.10
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 400 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
100 - 400 | £0.059 | £5.90 |
500 - 900 | £0.055 | £5.50 |
1000 - 1900 | £0.05 | £5.00 |
2000 - 4900 | £0.046 | £4.60 |
5000 + | £0.042 | £4.20 |
*price indicative
- RS Stock No.:
- 181-5380
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Capacitance | 220µF | |
Voltage | 10V dc | |
Mounting Type | Radial, Through Hole | |
Technology | Aluminium Electrolytic | |
Dimensions | 6 Dia. x 11mm | |
Height | 11mm | |
Minimum Operating Temperature | -40°C | |
Diameter | 6mm | |
Maximum Operating Temperature | 105°C | |
Lead Pitch | 2.5mm | |
Lifetime | 1000h | |
Tolerance | ±20% | |
Ripple Current | 350mA | |
Leakage Current | ≦0.01 CV or 3 μA @ 1 min | |
Dissipation Factor | 19% | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Capacitance 220µF | ||
Voltage 10V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 6 Dia. x 11mm | ||
Height 11mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 6mm | ||
Maximum Operating Temperature 105°C | ||
Lead Pitch 2.5mm | ||
Lifetime 1000h | ||
Tolerance ±20% | ||
Ripple Current 350mA | ||
Leakage Current ≦0.01 CV or 3 μA @ 1 min | ||
Dissipation Factor 19% | ||
- COO (Country of Origin):
- TW
RS PRO Electrolytic Capacitor
The RS PRO 220μF through-hole mount electrolytic capacitor has a voltage rating of 10VDC and leakage current of 3μA. This low impedance capacitor has dimensions of 6mm x 11mm (diameter x length). This capacitor is designed with a safety vent construction.
Features and Benefits
• Tolerance: ±20%
• Lifetime: 1000 hours
• Ripple current: 350mA
• Dissipation Factor: 19%
• Lead pitch: 2.5mm
• Impedance: 0.25ohm
• Operating temperature ranging between -40°C and 105°C
• Lifetime: 1000 hours
• Ripple current: 350mA
• Dissipation Factor: 19%
• Lead pitch: 2.5mm
• Impedance: 0.25ohm
• Operating temperature ranging between -40°C and 105°C
Applications
• Motherboard
• Computer peripheral
• Computer peripheral
Certifications
• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
• BS EN 61340-5-1:2007
