RS PRO 33μF Aluminium Electrolytic Capacitor 400V dc, Radial, Through Hole

View all Aluminium Capacitors
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
181-5136
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Capacitance

33µF

Voltage

400V dc

Mounting Type

Radial, Through Hole

Technology

Aluminium Electrolytic

Dimensions

16 Dia. x 26mm

Height

26mm

Minimum Operating Temperature

-25°C

Diameter

16mm

Maximum Operating Temperature

+105°C

Lead Pitch

7.5mm

Lifetime

1000h

Ripple Current

335mA

Tolerance

±20%

Leakage Current

3 μA

Dissipation Factor

15%

COO (Country of Origin):
TW

RS PRO Electrolytic Capacitor


The RS PRO 33μF through-hole mount electrolytic capacitor has a voltage rating of 400VDC and leakage current of 3μA. This low impedance capacitor has dimensions of 16mm x 26mm (diameter x length). This capacitor is designed with a safety vent construction.

Features and Benefits


• Tolerance: ±20%
• Lifetime: 1000 hours
• Ripple current: 355mA
• Dissipation factor: 15%
• Lead pitch: 7.5mm
• Load life: 3000∼10000 hours at 150 °C
• Impedance: 1.21ohm
• Operating temperature ranging between -25°C and 105°C
•

Applications


• Used in communication equipment
• Switching power supply
• Industrial measuring instruments

Certifications


• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
