RS PRO 470μF Electrolytic Capacitor 35V dc, Through Hole

View all Aluminium Capacitors
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
RS Stock No.:
181-5090
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Capacitance

470µF

Voltage

35V dc

Mounting Type

Through Hole

Technology

Electrolytic

Dimensions

10 Dia. x 15mm

Height

15mm

Minimum Operating Temperature

-40°C

Diameter

10mm

Maximum Operating Temperature

+105°C

Lead Pitch

5mm

Lifetime

1000h

Tolerance

±20%

Leakage Current

3 μA

Ripple Current

1A

Dissipation Factor

12%

COO (Country of Origin):
TW

RS PRO Electrolytic Capacitor


The RS PRO electrolytic capacitor has a safety vent design with through-hole mounting and features a capacitance of 470μF, at a rated voltage of 35VDC. The RS PRO capacitor has a lifetime of 1000 hours and tolerance is ±20%.

Features and Benefits


• Diameter is 10mm
• Dissipation factor is 12%
• Height is 15mm
• Lead pitch is 5mm
• Leakage current is 3μA
• Operating temperature ranging between -40°C and 105°C
• Ripple current is 1A
• Working voltage is 35VDC

Applications


• Computer peripheral
• Mother board

Certifications


• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
