RS PRO 1000μF Aluminium Electrolytic Capacitor 16V dc, Radial, Through Hole
- RS Stock No.:
- 181-5059
- Brand:
- RS PRO
Save 8% when you buy 3000 units
Subtotal (1 bag of 1000 units)*
£146.00
(exc. VAT)
£175.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 5,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
---|---|---|
1000 - 2000 | £0.146 | £146.00 |
3000 + | £0.133 | £133.00 |
*price indicative
- RS Stock No.:
- 181-5059
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Capacitance | 1000µF | |
Voltage | 16V dc | |
Mounting Type | Radial, Through Hole | |
Technology | Aluminium Electrolytic | |
Dimensions | 8 Dia. x 16mm | |
Height | 16mm | |
Minimum Operating Temperature | -40°C | |
Diameter | 8mm | |
Maximum Operating Temperature | 105°C | |
Lead Pitch | 3.5mm | |
Lifetime | 1000h | |
Leakage Current | ≦0.01 CV or 3 μA @ 1 min | |
Series | RS PRO | |
Tolerance | ±20% | |
Ripple Current | 1.05A | |
Dissipation Factor | 16% | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Capacitance 1000µF | ||
Voltage 16V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 8 Dia. x 16mm | ||
Height 16mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 8mm | ||
Maximum Operating Temperature 105°C | ||
Lead Pitch 3.5mm | ||
Lifetime 1000h | ||
Leakage Current ≦0.01 CV or 3 μA @ 1 min | ||
Series RS PRO | ||
Tolerance ±20% | ||
Ripple Current 1.05A | ||
Dissipation Factor 16% | ||
- COO (Country of Origin):
- TW
Used in mother board,computer peripheral,etc.
Safety vent construction design.
Safety vent construction design.
