KEMET 10000μF Aluminium Electrolytic Capacitor 63V dc, Press-Fit - ALF20C103EC063
- RS Stock No.:
- 175-7250
- Mfr. Part No.:
- ALF20C103EC063
- Brand:
- KEMET
Subtotal (1 pack of 72 units)*
£698.40
(exc. VAT)
£838.08
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
72 + | £9.70 | £698.40 |
*price indicative
- RS Stock No.:
- 175-7250
- Mfr. Part No.:
- ALF20C103EC063
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | KEMET | |
Capacitance | 10000µF | |
Voltage | 63V dc | |
Mounting Type | Press-Fit | |
Technology | Aluminium Electrolytic | |
Dimensions | 40 Dia. x 35mm | |
Height | 35mm | |
Minimum Operating Temperature | -40°C | |
Diameter | 40mm | |
Maximum Operating Temperature | +85°C | |
Lifetime | 18000h | |
Tolerance | ±20% | |
Polarised | Polar | |
Leakage Current | 3.78 mA | |
Ripple Current | 4.58 A @ 100 Hz, 4.67 A @ 10 kHz | |
Series | ALF20 | |
Equivalent Series Resistance | 80mΩ | |
Select all | ||
---|---|---|
Brand KEMET | ||
Capacitance 10000µF | ||
Voltage 63V dc | ||
Mounting Type Press-Fit | ||
Technology Aluminium Electrolytic | ||
Dimensions 40 Dia. x 35mm | ||
Height 35mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 40mm | ||
Maximum Operating Temperature +85°C | ||
Lifetime 18000h | ||
Tolerance ±20% | ||
Polarised Polar | ||
Leakage Current 3.78 mA | ||
Ripple Current 4.58 A @ 100 Hz, 4.67 A @ 10 kHz | ||
Series ALF20 | ||
Equivalent Series Resistance 80mΩ | ||
- COO (Country of Origin):
- PT
The KEMET ALF20 Press-Fit capacitors eliminate the need for solder, and therefore, the associated production and quality issues. They are the next evolution of snap-in capacitors, providing reliable electrical contact and the same vibration performance as soldered snap-in terminals.The ALF20 offers high voltages up to 600 VDC, high ripple currents, good surge voltage capability, and a very long life performance. Applications:The KEMET ALF20 capacitors are ideally suited for Industrial and commercial applications, demanding high reliability and long life expectancy.
Eliminates the manufacturing problems of soldering onto thick PCB copper tracks which act as heat-sinks
Eliminates fractured solder joints/cold solder
Capability to exchange components in the field
In addition to solving the solder issues, the ALF20 Press-Fit offers:
Compact size
Long life – up to 18,000 hours at +85°C
High ripple current
High voltage – up to 600 V
Excellent surge voltage capability
Eliminates fractured solder joints/cold solder
Capability to exchange components in the field
In addition to solving the solder issues, the ALF20 Press-Fit offers:
Compact size
Long life – up to 18,000 hours at +85°C
High ripple current
High voltage – up to 600 V
Excellent surge voltage capability
