KEMET 18000μF Aluminium Electrolytic Capacitor 400V dc, Screw Terminal - ALS70C183QS400
- RS Stock No.:
- 174-4552
- Mfr. Part No.:
- ALS70C183QS400
- Brand:
- KEMET
Bulk discount available
Subtotal (1 unit)*
£118.24
(exc. VAT)
£141.89
(inc. VAT)
Stock information currently inaccessible
Units | Per unit |
---|---|
1 - 4 | £118.24 |
5 - 9 | £111.15 |
10 + | £105.23 |
*price indicative
- RS Stock No.:
- 174-4552
- Mfr. Part No.:
- ALS70C183QS400
- Brand:
- KEMET
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | KEMET | |
Capacitance | 18000µF | |
Voltage | 400V dc | |
Mounting Type | Screw Terminal | |
Technology | Aluminium Electrolytic | |
Dimensions | 90 Dia. x 194mm | |
Height | 194mm | |
Minimum Operating Temperature | -40°C | |
Diameter | 90mm | |
Maximum Operating Temperature | +85°C | |
Lead Pitch | 31.8mm | |
Lifetime | 20000h | |
Leakage Current | 6 mA | |
Polarised | Polar | |
Tolerance | ±20% | |
Series | ALS70 | |
Equivalent Series Resistance | 13mΩ | |
Ripple Current | 37A | |
Select all | ||
---|---|---|
Brand KEMET | ||
Capacitance 18000µF | ||
Voltage 400V dc | ||
Mounting Type Screw Terminal | ||
Technology Aluminium Electrolytic | ||
Dimensions 90 Dia. x 194mm | ||
Height 194mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 90mm | ||
Maximum Operating Temperature +85°C | ||
Lead Pitch 31.8mm | ||
Lifetime 20000h | ||
Leakage Current 6 mA | ||
Polarised Polar | ||
Tolerance ±20% | ||
Series ALS70 | ||
Equivalent Series Resistance 13mΩ | ||
Ripple Current 37A | ||
KEMET's ALS70/71 high CV screw terminal capacitors offer tremendous performance and reliability in a wide range of case sizes and voltage ratings, featuring high ripple currents and long life performance. Volumetric efficiency ensures the maximum capacitance capability in a smaller size. They are ideally suited for industrial and commercial applications, demanding high reliability and long life expectancy such as frequency converters, uninterruptible power supply (UPS) systems and switch mode power supplies (SMPS).
Applications
Typical applications for KEMET's ALS70/71 series of capacitors include alternative energy, smoothing, energy storage or pulse operation, in telecommunication demanding power supplies, process control, AC motor control, traction, welding, and measuring.
Applications
Typical applications for KEMET's ALS70/71 series of capacitors include alternative energy, smoothing, energy storage or pulse operation, in telecommunication demanding power supplies, process control, AC motor control, traction, welding, and measuring.
Maximum capacitance capability in a smaller size
Long life, up to 20,000 hours at +85°C (Vr, Ir applied)
High ripple current
Excellent surge voltage capability
PET sleeve
Long life, up to 20,000 hours at +85°C (Vr, Ir applied)
High ripple current
Excellent surge voltage capability
PET sleeve
