CHEMI-CON 47μF Aluminium Electrolytic Capacitor 250V dc, Radial, Through Hole - EKXJ251ELL470MJ25S
- RS Stock No.:
- 170-0361
- Mfr. Part No.:
- EKXJ251ELL470MJ25S
- Brand:
- CHEMI-CON
Subtotal (1 box of 1000 units)*
£319.00
(exc. VAT)
£383.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 03 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 1000 + | £0.319 | £319.00 |
*price indicative
- RS Stock No.:
- 170-0361
- Mfr. Part No.:
- EKXJ251ELL470MJ25S
- Brand:
- CHEMI-CON
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Capacitance | 47µF | |
| Voltage | 250V dc | |
| Mounting Type | Radial, Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 10 (Dia.) x 25mm | |
| Height | 25mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 10mm | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 5mm | |
| Lifetime | 12000h | |
| Tolerance | ±20% | |
| Leakage Current | 570 μA | |
| Series | KXJ | |
| Ripple Current | 315mArms | |
Select all | ||
|---|---|---|
Brand CHEMI-CON | ||
Capacitance 47µF | ||
Voltage 250V dc | ||
Mounting Type Radial, Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 10 (Dia.) x 25mm | ||
Height 25mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 10mm | ||
Maximum Operating Temperature +105°C | ||
Lead Pitch 5mm | ||
Lifetime 12000h | ||
Tolerance ±20% | ||
Leakage Current 570 μA | ||
Series KXJ | ||
Ripple Current 315mArms | ||
- COO (Country of Origin):
- JP
KXJ Series
Miniature radial aluminium electrolytic capacitors downsized and longer life than the KXG series. Suitable for ballast circuits and other long life applications.
