Nichicon 2700μF Aluminium Electrolytic Capacitor 450V dc, Screw Terminal - LQR2W272MSEH
- RS Stock No.:
- 165-3859
- Mfr. Part No.:
- LQR2W272MSEH
- Brand:
- Nichicon
Bulk discount available
Subtotal (1 bag of 5 units)*
£279.86
(exc. VAT)
£335.83
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 5 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 5 - 5 | £55.972 | £279.86 |
| 10 + | £54.406 | £272.03 |
*price indicative
- RS Stock No.:
- 165-3859
- Mfr. Part No.:
- LQR2W272MSEH
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Capacitance | 2700µF | |
| Voltage | 450V dc | |
| Mounting Type | Screw Terminal | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 76.2 (Dia.) x 80mm | |
| Height | 80mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 76.2mm | |
| Maximum Operating Temperature | +85°C | |
| Lifetime | 5000h | |
| Leakage Current | 3300 μA | |
| Series | QR | |
| Tolerance | ±20% | |
| Ripple Current | 10A | |
Select all | ||
|---|---|---|
Brand Nichicon | ||
Capacitance 2700µF | ||
Voltage 450V dc | ||
Mounting Type Screw Terminal | ||
Technology Aluminium Electrolytic | ||
Dimensions 76.2 (Dia.) x 80mm | ||
Height 80mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 76.2mm | ||
Maximum Operating Temperature +85°C | ||
Lifetime 5000h | ||
Leakage Current 3300 μA | ||
Series QR | ||
Tolerance ±20% | ||
Ripple Current 10A | ||
- COO (Country of Origin):
- CN
QR Series
Clamp-fixing +85°C
Ideal for computer power supply applications or other applications that require long operational life
