Nichicon 2700μF Aluminium Electrolytic Capacitor 400V dc, Screw Terminal - LQR2G272MSEG
- RS Stock No.:
- 165-3849
- Mfr. Part No.:
- LQR2G272MSEG
- Brand:
- Nichicon
Subtotal (1 bag of 5 units)*
£301.82
(exc. VAT)
£362.185
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 10 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 5 + | £60.364 | £301.82 |
*price indicative
- RS Stock No.:
- 165-3849
- Mfr. Part No.:
- LQR2G272MSEG
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Capacitance | 2700µF | |
| Voltage | 400V dc | |
| Mounting Type | Screw Terminal | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 63.5 (Dia.) x 90mm | |
| Height | 90mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 63.5mm | |
| Maximum Operating Temperature | +85°C | |
| Lifetime | 5000h | |
| Ripple Current | 11.5A | |
| Series | QR | |
| Tolerance | ±20% | |
| Leakage Current | 3110 μA | |
Select all | ||
|---|---|---|
Brand Nichicon | ||
Capacitance 2700µF | ||
Voltage 400V dc | ||
Mounting Type Screw Terminal | ||
Technology Aluminium Electrolytic | ||
Dimensions 63.5 (Dia.) x 90mm | ||
Height 90mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 63.5mm | ||
Maximum Operating Temperature +85°C | ||
Lifetime 5000h | ||
Ripple Current 11.5A | ||
Series QR | ||
Tolerance ±20% | ||
Leakage Current 3110 μA | ||
- COO (Country of Origin):
- CN
QR Series
Clamp-fixing +85°C
Ideal for computer power supply applications or other applications that require long operational life
