Wurth Elektronik 470μF Aluminium Electrolytic Capacitor 16V dc, Surface Mount - 865060353009
- RS Stock No.:
- 163-6365
- Mfr. Part No.:
- 865060353009
- Brand:
- Wurth Elektronik
Subtotal (1 reel of 500 units)*
£208.50
(exc. VAT)
£250.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 27 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 500 + | £0.417 | £208.50 |
*price indicative
- RS Stock No.:
- 163-6365
- Mfr. Part No.:
- 865060353009
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Capacitance | 470µF | |
| Voltage | 16V dc | |
| Mounting Type | Surface Mount | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 10.5 (Dia.) x 7.85mm | |
| Height | 7.85mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 10.5mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 5000h | |
| Lead Pitch | 3.1mm | |
| Tolerance | ±20% | |
| Leakage Current | 75.2 μA | |
| Polarised | Polar | |
| Series | WCAP-ASLL | |
| Ripple Current | 600mA | |
| Dissipation Factor | 16 | |
Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Capacitance 470µF | ||
Voltage 16V dc | ||
Mounting Type Surface Mount | ||
Technology Aluminium Electrolytic | ||
Dimensions 10.5 (Dia.) x 7.85mm | ||
Height 7.85mm | ||
Minimum Operating Temperature -55°C | ||
Diameter 10.5mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 5000h | ||
Lead Pitch 3.1mm | ||
Tolerance ±20% | ||
Leakage Current 75.2 μA | ||
Polarised Polar | ||
Series WCAP-ASLL | ||
Ripple Current 600mA | ||
Dissipation Factor 16 | ||
- COO (Country of Origin):
- CN
Wurth Elektronik SMD Low Impedance, Long Life WCAP-ASLL Capacitor Series
WCAP-ASLL are low impedance long life Aluminium Electrolytic Capacitor Series
Features and Benefits
• Load life: 2000 h – 5000 h @ +105°C
• Operating temperature: -55°C to +105°C
• Reflow soldering recommended
• Operating temperature: -55°C to +105°C
• Reflow soldering recommended
