Wurth Elektronik 470μF Aluminium Electrolytic Capacitor 25V dc, Radial, Through Hole - 860240475009

RS Stock No.:: 163-6288
Mfr. Part No.:: 860240475009
Brand:: Wurth Elektronik

Wurth Elektronik 470μF Aluminium Electrolytic Capacitor 25V dc, Radial, Through Hole - 860240475009

Available to back order for despatch 25/11/2024

Price Each (In a Box of 500)

£0.348

(exc. VAT)

£0.418

(inc. VAT)

Units	Per unit	Per Box*
500 +	£0.348	£174.00

*price indicative

RS Stock No.:: 163-6288
Mfr. Part No.:: 860240475009
Brand:: Wurth Elektronik

Technical Reference

Datasheet

Legislation and Compliance

COO (Country of Origin):: CN

Product Details

Wurth Elektronik Long Life WCAP-AT1H Capacitor Series

WCAP- AT1H are Long Life Aluminium Electrolytic Capacitor Series
Higher permissible ripple current
Load life: 5000h – 10000h @ +105°C
Operating temperature: -40°C to +105°C for U_R < 400 V
-25°C to +105°C for U_R ≥ 400 V
Wave soldering recommended

Specifications

Attribute	Value
Capacitance	470µF
Voltage	25V dc
Mounting Type	Radial, Through Hole
Technology	Aluminium Electrolytic
Dimensions	10 (Dia.) x 20mm
Height	20mm
Minimum Operating Temperature	-40°C
Diameter	10mm
Maximum Operating Temperature	+105°C
Lifetime	10000h
Lead Pitch	5mm
Series	WCAP-AT1H
Tolerance	±20%
Ripple Current	950mA
Leakage Current	117.5 μA
Dissipation Factor	14
