Wurth Elektronik 22μF Aluminium Electrolytic Capacitor 25V dc, Radial, Through Hole - 860020472004

RS Stock No.:: 163-6185
Mfr. Part No.:: 860020472004
Brand:: Wurth Elektronik

Wurth Elektronik 22μF Aluminium Electrolytic Capacitor 25V dc, Radial, Through Hole - 860020472004

1400 In stock - FREE next working day delivery available

Price Each (In a Box of 2000)

£0.046

(exc. VAT)

£0.055

(inc. VAT)

Units	Per unit	Per Box*
2000 +	£0.046	£92.00

*price indicative

RS Stock No.:: 163-6185
Mfr. Part No.:: 860020472004
Brand:: Wurth Elektronik

Technical Reference

Legislation and Compliance

COO (Country of Origin):: CN

Product Details

Wurth Elektronik WCAP-ATG5 Series 105°C, 0.01μF- 330μF

WCAP-ATG5 Aluminium Electrolytic Capacitor series
High temperature, +105°C general purpose product series
Load life: 2000h @ +105°C
Reflow soldering recommended
Operating temperature: -40°C to +105°C for U_R < 400 V
-25 °C to +105°C for U_R ≥ 400 V

Specifications

Attribute	Value
Capacitance	22µF
Voltage	25V dc
Mounting Type	Radial, Through Hole
Technology	Aluminium Electrolytic
Dimensions	5 (Dia.) x 11mm
Height	11mm
Minimum Operating Temperature	-40°C
Diameter	5mm
Maximum Operating Temperature	+105°C
Lead Pitch	2mm
Lifetime	2000h
Tolerance	±20%
Series	WCAP-ATG5
Ripple Current	58mA
Leakage Current	5.5 μA
Dissipation Factor	14
