KEMET 24000μF Aluminium Electrolytic Capacitor 40V dc, Screw Terminal - ALS70A243DB040

View all Aluminium Capacitors

Subtotal (1 box of 50 units)*

£529.70

(exc. VAT)

£635.65

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 100 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Box*
50 +£10.594£529.70

*price indicative

RS Stock No.:
144-3104
Mfr. Part No.:
ALS70A243DB040
Brand:
KEMET
Find similar products by selecting one or more attributes.
Select all

Brand

KEMET

Capacitance

24000µF

Voltage

40V dc

Mounting Type

Screw Terminal

Technology

Aluminium Electrolytic

Dimensions

36 (Dia.) x 62mm

Height

62mm

Minimum Operating Temperature

-40°C

Diameter

36mm

Maximum Operating Temperature

+85°C

Lead Pitch

12.8mm

Lifetime

22000h

Leakage Current

6000 μA

Ripple Current

12.8A

Polarised

Polar

Tolerance

±20%

Series

ALS70

Equivalent Series Resistance

38mΩ

COO (Country of Origin):
PT
KEMET's ALS70/71 high CV screw terminal capacitors offer tremendous performance and reliability in a wide range of case sizes and voltage ratings, featuring high ripple current and long life performance. Volumetric efficiency ensures the maximum capacitance capability in a smaller size. They are ideally suited for industrial and commercial applications, demanding high reliability and long life expectancy such as frequency converters, uninterruptible power supply (UPS) systems and switch mode power supplies (SMPS).
