Wurth Elektronik 180μF Electrolytic Capacitor 450V dc Through Hole - 861111486031

Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): CN
Product Details

Wurth Elektronik WCAP-AIL5 Series Aluminium Electrolytic Capacitors

Wurth Elektronik WCAP- AIL5 Series aluminium electrolytic capacitors feature an operating temperature of up to +105°C. This general purpose capacitor family WCAP- AIL5 Series offer a capacitance value from 33uF to 330uF.

Specifications
Attribute Value
Capacitance 180 µF
Voltage 450 V dc
Mounting Type Through Hole
Technology Electrolytic
Dimensions 35 (Dia.) x 27mm
Depth 27mm
Minimum Operating Temperature -25°C
Diameter 35mm
Maximum Operating Temperature +105°C
Lifetime 2000h
Lead Pitch 10mm
Series WCAP-AIL5
Dissipation Factor 20%
Ripple Current 1.05A
Leakage Current 1620 μA
Polarised Polar
Tolerance ±20%
28 In stock for FREE next working day delivery
Price Each
£ 5.70
(exc. VAT)
£ 6.84
(inc. VAT)
Units
Per unit
1 - 9
£5.70
10 +
£5.42
