Non solid, low leakage current, low energy consumption and a long life Recommended for general and industrial applications in replacement for tantalum bead capacitors
Attribute
Value
Capacitance
4.7µF
Voltage
50V dc
Mounting Type
Radial, Through Hole
Technology
Aluminium Electrolytic
Dimensions
5 (Dia.) x 11mm
Height
11mm
Minimum Operating Temperature
-40°C
Diameter
5mm
Maximum Operating Temperature
+85°C
Lead Pitch
5mm
Lifetime
3000h
Leakage Current
1.5 μA
Tolerance
±20%
Series
013 RLC
Ripple Current
38mA
