Festo Branching Module for Festo D Series
- RS Stock No.:
- 203-1314
- Mfr. Part No.:
- FRM-1/8-D-MINI
- Brand:
- Festo
Subtotal (1 unit)*
£44.17
(exc. VAT)
£53.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 10 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £44.17 |
*price indicative
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£22.22
(exc. VAT)
£26.66
(inc. VAT)
- RS Stock No.:
- 203-1314
- Mfr. Part No.:
- FRM-1/8-D-MINI
- Brand:
- Festo
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Festo | |
| For Manufacturer Series | Festo D Series | |
| Accessory Type | Branching Module | |
| Series | Festo D Series | |
| Product Type | Branching Module | |
Select all | ||
|---|---|---|
Brand Festo | ||
For Manufacturer Series Festo D Series | ||
Accessory Type Branching Module | ||
Series Festo D Series | ||
Product Type Branching Module | ||
- COO (Country of Origin):
- HU
Festo Series D Porting Block, Branching Module, 1/8 inch Port size - FRM-1/8-D-MINI, Numeric Part Number: 164949
This porting block is a branching module designed to facilitate effective air distribution in pneumatic systems. Optimised for use with Festo D Series accessories, it enhances operational efficiency in various automated processes. This unit features a compact design with multiple pneumatic connections, ideal for intricate setups. Constructed from die-cast zinc, it ensures durability under a range of conditions, with a weight of 207g.
Features & Benefits
• Optional mounting position allows versatile installation
• Standard nominal flow rate of 1400 l/min enhances performance
• Functions with compressed air and inert gases for versatility
• Corrosion resistance class CRC 2 ensures longevity in various environments
• Operating medium compliant with ISO standards guarantees quality
• Temperature range from -10 °C to 60 °C for broad usability
• Standard nominal flow rate of 1400 l/min enhances performance
• Functions with compressed air and inert gases for versatility
• Corrosion resistance class CRC 2 ensures longevity in various environments
• Operating medium compliant with ISO standards guarantees quality
• Temperature range from -10 °C to 60 °C for broad usability
Applications
• Used in automation systems for efficient air management
• Ideal for industrial pneumatic setups requiring multiple branches
• Suitable for low to medium pressure systems in manufacturing
• Designed for installations where space is a constraint
• Utilised in pneumatic circuit design for optimised air flow
• Ideal for industrial pneumatic setups requiring multiple branches
• Suitable for low to medium pressure systems in manufacturing
• Designed for installations where space is a constraint
• Utilised in pneumatic circuit design for optimised air flow
What is the maximum operating pressure for this system?
The maximum operating pressure of this module is 1.6 MPa or 16 bar, allowing it to handle a range of applications effectively within specified limits.
How does the design optimise air distribution?
The branching module features multiple ports with varying sizes, which allows for efficient distribution of compressed air to different sections of a pneumatic system without significant loss of pressure.
Can this module be installed in any orientation?
Yes, the mounting position of this product is optional, providing flexibility in installation depending on the specific requirements of the application.
What type of pneumatic connections are available?
This unit includes G1/8 ports for ports one and two, and G1/4 ports for ports three and four, enabling compatibility with various hoses and components.
Is this product compliant with environmental standards?
Yes, it is RoHS-compliant, ensuring that it adheres to regulations regarding hazardous substances in manufacturing, making it suitable for modern industrial applications.
