Power Integrations, AC/DC Converter 1.23 A, 5 V dc, 50 V 7-Pin, SOIC
- RS Stock No.:
- 209-9576
- Mfr. Part No.:
- LNK3604G-TL
- Brand:
- Power Integrations
Bulk discount available
Subtotal (1 pack of 10 units)*
£5.63
(exc. VAT)
£6.76
(inc. VAT)
FREE delivery for orders over £60.00
Last RS stock
- Final 5,910 unit(s), ready to ship
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 40 | £0.563 | £5.63 |
| 50 - 90 | £0.551 | £5.51 |
| 100 - 240 | £0.388 | £3.88 |
| 250 - 490 | £0.38 | £3.80 |
| 500 + | £0.365 | £3.65 |
*price indicative
- RS Stock No.:
- 209-9576
- Mfr. Part No.:
- LNK3604G-TL
- Brand:
- Power Integrations
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Power Integrations | |
| Maximum Input Voltage | 265V ac | |
| Product Type | AC/DC Converter | |
| Maximum Output Voltage | 5V dc | |
| Mount Type | Surface | |
| Output Power | 6.1W | |
| Switching Frequency | 132kHz | |
| Pin Count | 7 | |
| Maximum Output Current | 1.23A | |
| Package Type | SOIC | |
| Minimum Input Voltage | 85V ac | |
| Topology | Flyback | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 150°C | |
| Height | 3.68mm | |
| Standards/Approvals | No | |
| Series | LinkSwitch-XT2 | |
| Length | 9.83mm | |
| Automotive Standard | No | |
| Minimum Output Current | 257mA | |
| Supply Current | 120μA | |
| Minimum Output Voltage | 50V | |
| Select all | ||
|---|---|---|
Brand Power Integrations | ||
Maximum Input Voltage 265V ac | ||
Product Type AC/DC Converter | ||
Maximum Output Voltage 5V dc | ||
Mount Type Surface | ||
Output Power 6.1W | ||
Switching Frequency 132kHz | ||
Pin Count 7 | ||
Maximum Output Current 1.23A | ||
Package Type SOIC | ||
Minimum Input Voltage 85V ac | ||
Topology Flyback | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 150°C | ||
Height 3.68mm | ||
Standards/Approvals No | ||
Series LinkSwitch-XT2 | ||
Length 9.83mm | ||
Automotive Standard No | ||
Minimum Output Current 257mA | ||
Supply Current 120μA | ||
Minimum Output Voltage 50V | ||
The Power integrations LNK3604D-TL package has power rating of 9.2 W. LinkSwitch™-XT2 incorporates a 725 V / 900 V power MOSFET, oscillator, simple ON/OFF control scheme, a high-voltage switched current source, frequency jittering, cycle-by-cycle current
Output overvoltage protection (OVP)
Input overvoltage line protection (OVL)
Hysteretic over-temperature protection (OTP)
Extended creepage between DRAIN pin and all other pins improves field reliability
725 V MOSFET rating series for excellent surge withs
