STMicroelectronics, High Voltage Switcher 504mA, 0 → 800 V 10-Pin, SSOP VIPER114HSTR
- RS Stock No.:
- 203-3527
- Mfr. Part No.:
- VIPER114HSTR
- Brand:
- STMicroelectronics
Bulk discount available
Subtotal (1 pack of 10 units)*
£20.91
(exc. VAT)
£25.09
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
10 - 40 | £2.091 | £20.91 |
50 - 90 | £2.051 | £20.51 |
100 - 240 | £1.778 | £17.78 |
250 - 990 | £1.735 | £17.35 |
1000 + | £1.691 | £16.91 |
*price indicative
- RS Stock No.:
- 203-3527
- Mfr. Part No.:
- VIPER114HSTR
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | STMicroelectronics | |
Mounting Type | Surface Mount | |
Pin Count | 10 | |
Maximum Output Current | 504mA | |
Dimensions | 5 x 6.20 x 5mm | |
Package Type | SSOP | |
Current Limit | 0.48A | |
Output Voltage Range | 0 → 800 V | |
Select all | ||
---|---|---|
Brand STMicroelectronics | ||
Mounting Type Surface Mount | ||
Pin Count 10 | ||
Maximum Output Current 504mA | ||
Dimensions 5 x 6.20 x 5mm | ||
Package Type SSOP | ||
Current Limit 0.48A | ||
Output Voltage Range 0 → 800 V | ||
- COO (Country of Origin):
- CN
The STMicroelectronics is an energy-saving, off-line high voltage converter. It integrates a 800 V avalanche-rugged power MOSFET with PWM current mode control in a smart way. The power MOSFET with 800 V breakdown voltage allows the extended input voltage range to be applied also the size of the DRAIN snubber circuit to be reduced. It meets the most stringent energy-saving standards as it has very low consumption and operates in pulse frequency modulation under light load. An integrated HV start-up, sense- FET, error amplifier and oscillator with jitter allow a complete application to be designed with the minimum number of components.
Design of buck, fly back and buck boost converters is supported
Pulse-skip protection in order to prevent flux-runaway
Embedded thermal shutdown
Has a built-in soft-start for improved system reliability
Pulse-skip protection in order to prevent flux-runaway
Embedded thermal shutdown
Has a built-in soft-start for improved system reliability
