STMicroelectronics, AC/DC Converter 0.38 A, 800V 10-Pin, SSO10 VIPER06HSTR
- RS Stock No.:
- 151-982
- Mfr. Part No.:
- VIPER06HSTR
- Brand:
- STMicroelectronics
Subtotal (1 reel of 2500 units)*
£872.50
(exc. VAT)
£1,047.50
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 20 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 2500 + | £0.349 | £872.50 |
*price indicative
- RS Stock No.:
- 151-982
- Mfr. Part No.:
- VIPER06HSTR
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Product Type | AC/DC Converter | |
| Maximum Input Voltage | 800V | |
| Maximum Output Voltage | 800V | |
| Output Power | 8W | |
| Mount Type | Surface | |
| Pin Count | 10 | |
| Switching Frequency | 115kHz | |
| Maximum Output Current | 0.38A | |
| Package Type | SSO10 | |
| Minimum Input Voltage | 11.5V | |
| Maximum Duty Cycle | 80% | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 150°C | |
| Length | 9.75mm | |
| Series | VIPER06 | |
| Standards/Approvals | RoHS Compliant | |
| Height | 3.32mm | |
| Supply Current | 1.6mA | |
| Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Product Type AC/DC Converter | ||
Maximum Input Voltage 800V | ||
Maximum Output Voltage 800V | ||
Output Power 8W | ||
Mount Type Surface | ||
Pin Count 10 | ||
Switching Frequency 115kHz | ||
Maximum Output Current 0.38A | ||
Package Type SSO10 | ||
Minimum Input Voltage 11.5V | ||
Maximum Duty Cycle 80% | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 150°C | ||
Length 9.75mm | ||
Series VIPER06 | ||
Standards/Approvals RoHS Compliant | ||
Height 3.32mm | ||
Supply Current 1.6mA | ||
- COO (Country of Origin):
- CN
The STMicroelectronics converter with an 800 V avalanche rugged power section, a PWM controller, a user-defined overcurrent limit, open-loop failure protection, hysteretic thermal protection, soft startup and safe auto-restart after any fault condition. The device is able to power itself directly from the rectified mains, eliminating the need for an auxiliary bias winding. Advanced frequency jittering reduces EMI filter cost.
Limiting current with adjustable set point
Safe auto-restart after a fault condition
Hysteretic thermal shutdown
