Weidmüller, OMNIMATE Signal Male PCB Header, 3.81 mm Pitch, 10 Way, 2 Row 90°
- RS Stock No.:
- 255-8282
- Mfr. Part No.:
- 1973760000
- Brand:
- Weidmüller
Subtotal (1 box of 50 units)*
£209.58
(exc. VAT)
£251.50
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 08 December 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £209.58 | £4.192 |
*price indicative
- RS Stock No.:
- 255-8282
- Mfr. Part No.:
- 1973760000
- Brand:
- Weidmüller
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Weidmüller | |
| Product Type | PCB Header | |
| Number of Contacts | 10 | |
| Number of Rows | 2 | |
| Pitch | 3.81mm | |
| Connector Gender | Male | |
| Mount Type | Board | |
| For Use With | PCB | |
| Orientation | 90° | |
| Length | 3.2mm | |
| Housing Material | Liquid Crystal Polymer Fibreglass, Copper Alloy | |
| Width | 20.44mm | |
| Standards/Approvals | UL 94, UL, IEC 61984, IEC 60664-1, DIN VDE 57 106, DIN VDE 0470, CSA | |
| Series | OMNIMATE Signal | |
| Select all | ||
|---|---|---|
Brand Weidmüller | ||
Product Type PCB Header | ||
Number of Contacts 10 | ||
Number of Rows 2 | ||
Pitch 3.81mm | ||
Connector Gender Male | ||
Mount Type Board | ||
For Use With PCB | ||
Orientation 90° | ||
Length 3.2mm | ||
Housing Material Liquid Crystal Polymer Fibreglass, Copper Alloy | ||
Width 20.44mm | ||
Standards/Approvals UL 94, UL, IEC 61984, IEC 60664-1, DIN VDE 57 106, DIN VDE 0470, CSA | ||
Series OMNIMATE Signal | ||
- COO (Country of Origin):
- CN
The Weidmuller PCB plug-in connector high-temperature-resistant two-tier SCD-THR pin header for reflow soldering.
It allows you to use two interfaces on only one surface and with only one step in the work flow
Outlet direction 90° (recumbent)
Connections at the same level and with access That is flush over the front board
Space for labelling and coding
