Wurth Elektronik, WR-WTB Female Crimp Connector Housing, 1mm Pitch, 8 Way, 1 Row Horizontal
- RS Stock No.:
- 177-0021
- Mfr. Part No.:
- 665008113322
- Brand:
- Wurth Elektronik
780 In stock - FREE next working day delivery available
200 available from Europe for delivery within 2 working day(s).
Price Each (In a Pack of 10)
£0.546
(exc. VAT)
£0.655
(inc. VAT)
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 40 | £0.546 | £5.46 |
| 50 - 90 | £0.492 | £4.92 |
| 100 - 240 | £0.448 | £4.48 |
| 250 - 490 | £0.41 | £4.10 |
| 500 + | £0.378 | £3.78 |
*price indicative
- RS Stock No.:
- 177-0021
- Mfr. Part No.:
- 665008113322
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
The Wurth Elektronik WR-WTB is a 8 pin, 1.00mm white female terminal housing for use with wire to board connectors.
RoHS compliant
Halogen free
Operating temperature ranging between -25°C up to +85°C
Withstanding voltage : 500V AC
Halogen free
Operating temperature ranging between -25°C up to +85°C
Withstanding voltage : 500V AC
Specifications
Attribute | Value |
|---|---|
| Number of Contacts | 8 |
| Number of Rows | 1 |
| Pitch | 1mm |
| Gender | Female |
| Mounting Type | Cable Mount |
| Series | WR-WTB |
| For Use With | Wire to Board Connectors |
| Body Orientation | Horizontal |
| Length | 11mm |
| Width | 5mm |
| Housing Material | Nylon |
