Sensata / Crydom SeriesOneDR Series DIN Rail Mount Timer Relay, 180 → 240V ac/dc, 2-Contact, 0.1 s →

RS Stock No.:: 144-5926
Mfr. Part No.:: DRTU24A06
Brand:: Sensata / Crydom

Sensata / Crydom SeriesOneDR Series DIN Rail Mount Timer Relay, 180 → 240V ac/dc, 2-Contact, 0.1 s →

View all Timer Relays

Discontinued product

RS Stock No.:: 144-5926
Mfr. Part No.:: DRTU24A06
Brand:: Sensata / Crydom

Technical Reference

Legislation and Compliance

COO (Country of Origin):: MX

Product Details

Crydom SeriesOne DR Solid State Timers

Crydom SeriesOne DR DIN Rail-mounted solid state relay timers with AC or DC output voltage. The solid-state timers are available in a variety of industry standard timing functions and various input and output voltage options.

Features and Benefits

Single channel 6 A output power rating

Compact size (11 mm wide)

8 industry standard functions available

IP20 housing with unique integrated heat sink design

LED status indicator

Solid-State Time Delay Relays

Specifications

Attribute	Value
Supply Voltage	180 → 240V ac/dc
Mounting Type	DIN Rail
Mode of Operation	Multifunction
Time Range	0.1 s → 100h
Number of Contacts	2
Number of Timer Functions	Multi Function
Contact Configuration	SPST
Time Increment	Hours, Minutes, Seconds
Maximum Current	6A
Maximum Voltage	240V ac/dc
Terminal Type	Screw
Switch Configuration	Solid State
Power Supply	External
Minimum Voltage	180V ac/dc
Width	11mm
Depth	83mm
Series	SeriesOneDR
Minimum Current	150mA
Maximum Operating Temperature	+80°C
Length	87.7mm
Time Delay	100ms
Minimum Operating Temperature	-30°C
