Yageo 100 Ω Carbon Film Carbon Film Fixed Resistor 1.6 W 5 %
- RS Stock No.:
- 199-1822
- Mfr. Part No.:
- CFR-12JT-52-100R
- Brand:
- Yageo
Subtotal (1 box of 5000 units)*
£45.00
(exc. VAT)
£55.00
(inc. VAT)
FREE delivery for orders over £50.00
Stock information currently inaccessible
Units | Per unit | Per Box* |
|---|---|---|
| 5000 + | £0.009 | £45.00 |
*price indicative
- RS Stock No.:
- 199-1822
- Mfr. Part No.:
- CFR-12JT-52-100R
- Brand:
- Yageo
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Yageo | |
| Product Type | Carbon Film Fixed Resistor | |
| Resistance | 100Ω | |
| Power Rating | 1.6W | |
| Resistor Type | High Stability | |
| Tolerance ± | 5% | |
| Voltage | 150 V | |
| Technology | Carbon Film | |
| Series | CFR | |
| Automotive Standard | AEC-Q200 | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 155°C | |
| Standards/Approvals | No | |
| Diameter | 1.9 mm | |
| Length | 3.4mm | |
| Temperature Coefficient | ppm/°C, -500 to +350 ppm/°C | |
| Lead Diameter | 0.45mm | |
| Select all | ||
|---|---|---|
Brand Yageo | ||
Product Type Carbon Film Fixed Resistor | ||
Resistance 100Ω | ||
Power Rating 1.6W | ||
Resistor Type High Stability | ||
Tolerance ± 5% | ||
Voltage 150 V | ||
Technology Carbon Film | ||
Series CFR | ||
Automotive Standard AEC-Q200 | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 155°C | ||
Standards/Approvals No | ||
Diameter 1.9 mm | ||
Length 3.4mm | ||
Temperature Coefficient ppm/°C, -500 to +350 ppm/°C | ||
Lead Diameter 0.45mm | ||
- COO (Country of Origin):
- CN
The Yageo CFR series 100O is a carbon film resistor which is manufactured by coating a homogeneous film of pure carbon on high grade ceramic rods and after a helical groove has been cut in the resistive layer tinned connecting leads of electrolytic copper are welded to the endcaps where the resistor is coated with layers of tan colour lacquer.
Insulation Resistance :in V-block for 60 Sec
Temperature coefficient (ppm/°C): -500∼350
Maximum Working Voltage:250V
