Vishay Thermistor, 260Ω Resistance, PTC Type, 5 x 5.5mm
- RS Stock No.:
- 252-715
- Mfr. Part No.:
- PTCCL05H390HBE
- Brand:
- Vishay
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 252-715
- Mfr. Part No.:
- PTCCL05H390HBE
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Series | PTCCL | |
| Temperature Coefficient Type | PTC | |
| Resistance @ 25 °C | 260Ω | |
| Tolerance | ±20% | |
| Length | 30mm | |
| Depth | 5.5mm | |
| Height | 10mm | |
| Maximum Operating Temperature | +70°C | |
| Minimum Operating Temperature | 0°C | |
| Dimensions | 5 x 5.5mm | |
Select all | ||
|---|---|---|
Brand Vishay | ||
Series PTCCL | ||
Temperature Coefficient Type PTC | ||
Resistance @ 25 °C 260Ω | ||
Tolerance ±20% | ||
Length 30mm | ||
Depth 5.5mm | ||
Height 10mm | ||
Maximum Operating Temperature +70°C | ||
Minimum Operating Temperature 0°C | ||
Dimensions 5 x 5.5mm | ||
- COO (Country of Origin):
- CN
Thermistors PTC series 660, 661 and 662
PTCs are semiconductor resistors whose resistance, at zero dissipation, increases with the temperature within a determined range.
The temperature variation is obtained either by joule effect, by variation in ambient temperature, or a combination of the two.
Fields of application: stabilisation of current, protection, sensor.
The temperature variation is obtained either by joule effect, by variation in ambient temperature, or a combination of the two.
Fields of application: stabilisation of current, protection, sensor.
