IP67 Blue Side Cap Tactile Switch, Single Pole Single Throw (SPST) 50 mA 6.5 (Dia.)mm PCB

  • RS Stock No. 912-0399
  • Mfr. Part No. RA3FTH900
  • Brand MEC
Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): DK
Product Details

Multimec® 3F Switches

SPNO momentary action
Sealed to IP67

Specifications
Attribute Value
Contact Configuration Single Pole Single Throw (SPST)
Terminal Type Pc Pin
Switch Operation Momentary
Actuator Length 6.5 (Dia.)mm
Actuator Colour Blue
Actuator Type Side Cap
Length 12.5mm
Width 10.4mm
Dimensions 12.5 x 10.4mm
Illuminated Yes
Mounting Type PCB
Contact Current Rating 50 mA
IP Rating IP67
Operating Force 3.5 N
Operating Temperature Range -40 → +160°C
Minimum Operating Temperature -40°C
Mechanical Life 10000000Operations
Voltage Rating 24V dc
Maximum Operating Temperature +160°C
309 In stock for FREE next working day delivery
Price Each
£ 5.86
(exc. VAT)
£ 7.03
(inc. VAT)
Units
Per unit
1 - 9
£5.86
10 - 24
£5.60
25 +
£4.42
