MEAN WELL, PSPA-1000-48 Switching Power Supply 48V dc, 1.008 kW 370 V dc, 264V ac

Subtotal (1 unit)*

£132.16

(exc. VAT)

£158.59

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 17 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£132.16

*price indicative

RS Stock No.:
176-3466
Distrelec Article No.:
303-72-483
Mfr. Part No.:
PSPA-1000-48
Brand:
MEAN WELL
Find similar products by selecting one or more attributes.
Select all

Brand

MEAN WELL

Product Type

Switching Power Supply

Maximum Output Voltage

48V dc

Number of Outputs

1

Mount Type

Chassis

Power

1.008kW

SMPS Output Current

21A

Minimum Operating Temperature

-20°C

Maximum Operating Temperature

70°C

Width

93mm

Standards/Approvals

UL 62368-1, TUV BS EN/EN 62368-1, IS 13252(Part1)/IEC 60950-1, EAC TP TC 00, CSA C22.2 No. 62368-1, CCCGB4943.1, BSMI CNS143361, AS/NZS62368.1

Weight

1.9kg

Length

170mm

Depth

93mm

Maximum Input Voltage

370V dc, 264V dc

Series

PSPA-1000

Efficiency

94%

Minimum Input Voltage

90V ac

Hazardous Area Certification

No

Output Current

21A

COO (Country of Origin):
TW
The outstanding feature for PSPA-1000 is sharing the same mechanism with PSP-600. Customers can replace 600W power supply with 1000W one without modifying space. Other features include high efficiency up to 94%, wide working temperature range -20℃∼70℃, remote control functions (remote ON/OFF, remote sense, and DC OK signal), and parallel power up to 4000W. With various functions, PSPA-1000 is suitable for industrial control, electric motor, communication systems and network equipment, etc.

90∼264VAC full range input

Built-in active PFC function

Forced air cooling by built-in DC fan

Current sharing up to 4000W

Remote control functions: remote ON/OFF, remote sense, DC OK signal

Protections: short circuit/overload/ over voltage/ over temperature

Dimensions(L x W x H): 170 x 120 x 93mm

5 years warranty

AC-DC Single output Enclosed power supply, Output 48Vdc at 21A, PFC and Parallel function, remote ON/OFF, DC OK signal
