MEAN WELL Switching Power Supply, MPM-30-12, 12V dc, 2.5A, 30W, 1 Output, 80 → 264V ac Input Voltage

View all Switching Power Supplies
Currently unavailable
Sorry, we don't know when this will be back in stock.
RS Stock No.:
174-8070
Distrelec Article No.:
303-72-455
Mfr. Part No.:
MPM-30-12
Brand:
MEAN WELL
Find similar products by selecting one or more attributes.
Select all

Brand

MEAN WELL

Output Voltage

12V dc

Output Current

2.5A

Power Rating

30W

Number of Outputs

1

Input Voltage

80 → 264V ac

Mounting Type

PCB Mount

Package Type

Encapsulated

Length

69.5mm

Width

39mm

Medical Approved

Yes

Depth

24mm

Maximum Temperature

+85°C

Minimum Temperature

-40°C

Weight

102g

COO (Country of Origin):
CN
2.73"x1.53" compact size

Suitable for BF application with appropriate system consideration
No load power consumption<0.075W
Extremely low leakage current
Wide operating temp. Range -40 ∼ +85℃
EMI class B for class Ⅱ configuration
Protections: Short circuit / Overload / Over voltage
No minimum load required
3 years warranty
Applications
Portable medical device
Mobile clinical workstation
Medical computer monitor
Medical examination instrument

AC-DC Single output Medical Encapsulated power supply. Output 12Vdc at 2.5A, PCB through hole, 2xMOPP
