MEAN WELL Switching Power Supply, IRM-60-5ST, 5V dc, 10A, 50W, 1 Output, 85 → 264V ac Input Voltage
- RS Stock No.:
- 135-8972
- Distrelec Article No.:
- 300-60-603
- Mfr. Part No.:
- IRM-60-5ST
- Brand:
- MEAN WELL
Subtotal (1 unit)*
£17.60
(exc. VAT)
£21.12
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 19 unit(s) shipping from 22 October 2025
- Plus 14 unit(s) shipping from 22 October 2025
- Plus 50 unit(s) shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £17.60 |
*price indicative
- RS Stock No.:
- 135-8972
- Distrelec Article No.:
- 300-60-603
- Mfr. Part No.:
- IRM-60-5ST
- Brand:
- MEAN WELL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | MEAN WELL | |
Output Voltage | 5V dc | |
Output Current | 10A | |
Power Rating | 50W | |
Number of Outputs | 1 | |
Input Voltage | 85 → 264V ac | |
Mounting Type | Chassis Mount | |
Package Type | Encapsulated | |
Length | 109mm | |
Width | 52mm | |
Depth | 33.5mm | |
Series | IRM-60 | |
Weight | 270g | |
Minimum Temperature | -30°C | |
Maximum Temperature | +70°C | |
Select all | ||
---|---|---|
Brand MEAN WELL | ||
Output Voltage 5V dc | ||
Output Current 10A | ||
Power Rating 50W | ||
Number of Outputs 1 | ||
Input Voltage 85 → 264V ac | ||
Mounting Type Chassis Mount | ||
Package Type Encapsulated | ||
Length 109mm | ||
Width 52mm | ||
Depth 33.5mm | ||
Series IRM-60 | ||
Weight 270g | ||
Minimum Temperature -30°C | ||
Maximum Temperature +70°C | ||
Mean Well IRM-60 Series 60 W Single Output Encapsulated AC-DC Power Supply
From Mean Well, the IRM-60 Series of encapsulated AC-DC power supplies are constructed from a 94V-0 flame retardant plastic case and fully potted silicone. The construction meets anti-vibration demand up to 5G and provides resistance to dust and moisture while enhancing heat dissipation. The IRM-60 series is a 60 W compact solution and is ready to solder straight onto PCB boards. Featuring a universal input voltage range of 85 V ac to 264 V ac, these AC-DC module power supplies are highly versatile. Featuring low no-load power consumption below 0.1 W and high efficiency up to 91%, these switching power supplies meet worldwide regulations for power consumption. IRM-60 power supplies are a Class II design and include built-in EMI filtering components and excellent EMC features that prevent electromagnetic interference.
Features and Benefits:
High efficiency up to 91% (depending on model)
Isolation Class II
Compact size
Overvoltage, overload and short circuit protection
Universal AC input with full range
Cooled by free air convection
100% full load burn-in test
Pass LPS (except for 5 V)
High reliability
Choice of PCB mounting or screw terminals
Product Applications:
Suitable applications include hand held electronic devices, factory automation equipment, mechanical equipment and industrial electrical equipment.
Standards
Safety standards: UL60950-1, TUV EN60950-1 approved
EMC emission: Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3
EMC immunity: Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, heavy industry level (surge L-N: 1 KV), criteria A
EMC emission: Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3
EMC immunity: Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, heavy industry level (surge L-N: 1 KV), criteria A
Note
Available on EPLAN.
