MEAN WELL Switching Power Supply, IRM-03-9S, 9V dc, 333mA, 3W, 1 Output, 120 → 430 V dc, 85 → 305 V ac

RS Stock No.:: 135-8918
Mfr. Part No.:: IRM-03-9S
Brand:: MEAN WELL

MEAN WELL Switching Power Supply, IRM-03-9S, 9V dc, 333mA, 3W, 1 Output, 120 → 430 V dc, 85 → 305 V ac

Sorry, we couldn't check our stock levels right now. Please try refreshing the page.

Not available for guaranteed pre 9am/10am delivery

Price 1 Tube of 10

£52.41

(exc. VAT)

£62.89

(inc. VAT)

Tube(s)	Per Tube	Per unit*
1 - 4	£52.41	£5.241
5 - 9	£50.96	£5.096
10 - 24	£49.58	£4.958
25 - 49	£48.28	£4.828
50 +	£47.04	£4.704

*price indicative

RS Stock No.:: 135-8918
Mfr. Part No.:: IRM-03-9S
Brand:: MEAN WELL

Technical Reference

IRM-03 Series Datasheet

Legislation and Compliance

Product Details

Mean Well IRM-03 Series 3 W Single Output Encapsulated AC-DC Power Supply

From Mean Well, the IRM-03 Series of encapsulated AC-DC power supplies are constructed from a phenolic case and fully potted silicone. The construction meets anti-vibration demand up to 5G and provides resistance to dust and moisture while enhancing heat dissipation. The IRM-03 series is a 3 W miniature solution and is ready to solder straight onto PCB boards. Featuring a universal input voltage range of 85 V ac to 305 V ac, these AC-DC module power supplies are highly versatile. Featuring low no-load power consumption below 0.075 W and high efficiency up to 80%, these switching power supplies meet worldwide regulations for power consumption. IRM-03 power supplies are a Class II design and feature built-in EMI filtering components and excellent EMC filtering components that prevent electromagnetic interference.

Features and Benefits:

High efficiency up to 80% (depending on model)

Isolation Class II

Compact size

Overvoltage, overload and short circuit protection

Cooled by free air convection

Universal AC input with full range

Available with either PCB or SMD mounting

Complies with EN55022 Class B without the need for any additional components

Product Applications

Suitable applications include hand held electronic devices, factory automation equipment, mechanical equipment and industrial electrical equipment.

Standards

Safety standards: UL60950-1, TUV EN60950, TUV EN60335-1 approved, Meet IEC60601-1, EN61558-1/-2-16
EMC emission: Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3
EMC immunity: Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11, EN55024, heavy industry level (surge L-N: 1 KV), criteria A

Specifications

Attribute	Value
Output Voltage	9V dc
Output Current	333mA
Power Rating	3W
Number of Outputs	1
Input Voltage	120 → 430 V dc, 85 → 305 V ac
Mounting Type	Surface Mount
Package Type	Encapsulated
Length	37mm
Width	24mm
Depth	16mm
Efficiency	77%
Minimum Temperature	-30°C
Weight	20g
Maximum Temperature	+85°C
