MEAN WELL, PSP-600-15 Switching Power Supply 15V dc, 600 W 230V
- RS Stock No.:
- 149-466
- Mfr. Part No.:
- PSP-600-15
- Brand:
- MEAN WELL
Subtotal (1 box of 8 units)*
£823.90
(exc. VAT)
£988.68
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 1 unit(s) shipping from 16 October 2026
- Plus 1 unit(s) shipping from 23 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £823.90 | £102.988 |
*price indicative
- RS Stock No.:
- 149-466
- Mfr. Part No.:
- PSP-600-15
- Brand:
- MEAN WELL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Product Type | Switching Power Supply | |
| Maximum Output Voltage | 15V dc | |
| Number of Outputs | 1 | |
| Power | 600W | |
| Minimum Operating Temperature | -20°C | |
| SMPS Output Current | 40A | |
| Maximum Operating Temperature | 60°C | |
| Weight | 1.84kg | |
| Standards/Approvals | UKCA, EAC, CRULS, CE, CB | |
| Depth | 93mm | |
| Length | 170mm | |
| Width | 120mm | |
| Series | PSP | |
| Efficiency | 85% | |
| Maximum Input Voltage | 230V | |
| Output Current | 40A | |
| Hazardous Area Certification | No | |
| Minimum Input Voltage | 110V | |
| Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Product Type Switching Power Supply | ||
Maximum Output Voltage 15V dc | ||
Number of Outputs 1 | ||
Power 600W | ||
Minimum Operating Temperature -20°C | ||
SMPS Output Current 40A | ||
Maximum Operating Temperature 60°C | ||
Weight 1.84kg | ||
Standards/Approvals UKCA, EAC, CRULS, CE, CB | ||
Depth 93mm | ||
Length 170mm | ||
Width 120mm | ||
Series PSP | ||
Efficiency 85% | ||
Maximum Input Voltage 230V | ||
Output Current 40A | ||
Hazardous Area Certification No | ||
Minimum Input Voltage 110V | ||
RoHS Status: Exempt
- COO (Country of Origin):
- TW
The MEANWELL single output enclosed power supply with an output of 15Vdc at 40A. It is a highly reliable and efficient power supply that is suitable for a wide range of applications. With a power rating of 600W and a Compact design, It delivers stable and clean power with minimal ripple and noise. It also features a PFC (Power Factor Correction) function, ensuring efficient power usage. This is designed to comply with safety standards and has protection features such as overvoltage and over temperature protection. With its robust construction and excellent performance, It is the perfect power supply for industrial and commercial applications.
Single output enclosed power supply
Output of 15Vdc at 40A
Power rating of 600W
Compact design with high efficiency
Minimal ripple and noise
PFC (Power Factor Correction) function for efficient power usage
Complies with safety standards
Overvoltage and over temperature protection for enhanced safety
Suitable for a wide range of applications
