Bourns, SRP5030T, 5030 Shielded Wirewound Surface Mount Inductor with a Powdered Iron Core, 1.2 μH ±20 % 6.5 A Idc
- RS Stock No.:
- 776-3975P
- Mfr. Part No.:
- SRP5030T-1R2M
- Brand:
- Bourns
Bulk discount available
Subtotal 25 units (supplied on a continuous strip)*
£17.55
(exc. VAT)
£21.05
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 1,840 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 25 + | £0.702 |
*price indicative
- RS Stock No.:
- 776-3975P
- Mfr. Part No.:
- SRP5030T-1R2M
- Brand:
- Bourns
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bourns | |
| Product Type | Wirewound Surface Mount Inductor | |
| Inductance | 1.2μH | |
| Maximum DC Current | 6.5A | |
| Package/Case | 5030 | |
| Length | 5.7mm | |
| Packaging | Reel | |
| Automotive Standard | No | |
| Shielding | Yes | |
| Minimum Operating Temperature | -40°C | |
| Maximum DC Resistance | 16mΩ | |
| Inductance Tolerance | ±20 % | |
| Series | SRP5030T | |
| Maximum Operating Temperature | 125°C | |
| Depth | 5.2mm | |
| Height | 2.8mm | |
| Core Material | Powdered Iron | |
| Standards/Approvals | RoHS | |
| Termination Style | Surface Mount | |
| Inductor Construction | Wirewound | |
| Moulded | Yes | |
| Select all | ||
|---|---|---|
Brand Bourns | ||
Product Type Wirewound Surface Mount Inductor | ||
Inductance 1.2μH | ||
Maximum DC Current 6.5A | ||
Package/Case 5030 | ||
Length 5.7mm | ||
Packaging Reel | ||
Automotive Standard No | ||
Shielding Yes | ||
Minimum Operating Temperature -40°C | ||
Maximum DC Resistance 16mΩ | ||
Inductance Tolerance ±20 % | ||
Series SRP5030T | ||
Maximum Operating Temperature 125°C | ||
Depth 5.2mm | ||
Height 2.8mm | ||
Core Material Powdered Iron | ||
Standards/Approvals RoHS | ||
Termination Style Surface Mount | ||
Inductor Construction Wirewound | ||
Moulded Yes | ||
- COO (Country of Origin):
- TW
SRP5030T Series Magnetically Shielded Wire Wound Chokes
Shielded construction
Iron powder core
High saturation current
Applications include DC/DC convertors and power supplies for portable equipment
