Magnetically shielded SMD fixed inductors with low DC resistance and suitable for large currents. 12.3mm (Max.) square and 8.0mm (Max.) height, these inductors can be used for DC-DC converter applications in handheld personal computers.
Toko Non Standard SMT Inductors (Chokes)
Attribute
Value
Inductance
42 μH
Maximum DC Current
3.3A
Package/Case
D128C
Length
12.3mm
Depth
12.3mm
Height
8mm
Dimensions
12.3 x 12.3 x 8mm
Shielded
Yes
Tolerance
±20%
Maximum DC Resistance
52.6mΩ
Series
D128C
Core Material
Ferrite
Inductor Construction
Wire-Wound
