Wurth Elektronik, WELQS 220 Shielded Surface Mount Inductor 220 μH 0.95 A Idc
- RS Stock No.:
- 548-615P
- Mfr. Part No.:
- 74404086221
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal 50 units (supplied on a continuous strip)*
£38.20
(exc. VAT)
£45.85
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 500 unit(s) shipping from 20 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 50 - 245 | £0.764 |
| 250 - 495 | £0.584 |
| 500 + | £0.546 |
*price indicative
- RS Stock No.:
- 548-615P
- Mfr. Part No.:
- 74404086221
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Inductance | 220μH | |
| Product Type | Surface Mount Inductor | |
| Maximum DC Current | 0.95A | |
| Length | 8mm | |
| Packaging | Tape & Reel | |
| Automotive Standard | AEC-Q200 | |
| Shielding | Yes | |
| Maximum DC Resistance | 555mΩ | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 125°C | |
| Series | WELQS 220 | |
| Diameter | 6.5mm | |
| Standards/Approvals | Halogen-Free, RoHS, REACH | |
| Depth | 6.5mm | |
| Termination Style | Package | |
| Height | 6.5mm | |
| Inductor Construction | Wirewound | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Inductance 220μH | ||
Product Type Surface Mount Inductor | ||
Maximum DC Current 0.95A | ||
Length 8mm | ||
Packaging Tape & Reel | ||
Automotive Standard AEC-Q200 | ||
Shielding Yes | ||
Maximum DC Resistance 555mΩ | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 125°C | ||
Series WELQS 220 | ||
Diameter 6.5mm | ||
Standards/Approvals Halogen-Free, RoHS, REACH | ||
Depth 6.5mm | ||
Termination Style Package | ||
Height 6.5mm | ||
Inductor Construction Wirewound | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik Semi shielded SMT power inductor boasts a compact design that delivers 1.7 times more current capacity compared to its unshielded counterparts, making it ideal for high efficiency applications. Its robust construction ensures minimal acoustic noise and reduced electromagnetic interference, enhancing overall system performance. With an operating temperature range suitable for various environments, this inductor is well-suited for integrated DC/DC converters, switching controllers, and portable power devices such as PDAs, smartphones, digital cameras, and LCD TVs.
Robust construction
Low RDC
Magnetically shielded by use of a magnetic resin
