Celduc SO8 Series Solid State Relay, 50 A Load, Panel Mount, 690 V ac Load, 265V ac/dc Control
- RS Stock No.:
- 917-4807
- Mfr. Part No.:
- SO885960
- Brand:
- Celduc
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 917-4807
- Mfr. Part No.:
- SO885960
- Brand:
- Celduc
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Celduc | |
| Maximum Load Current | 50 A | |
| Mounting Type | Panel Mount | |
| Maximum Load Voltage | 690 V ac | |
| Minimum Load Voltage | 24 V ac | |
| Minimum Control Voltage | 20V ac/dc | |
| Maximum Control Voltage | 265V ac/dc | |
| Switching Type | Zero Cross | |
| Control Voltage Range | 20 → 265 V ac/dc | |
| Range | SO8 | |
| Number of Poles | 1 | |
| Terminal Type | Screw | |
| Output Device | Thyristor | |
| Relay Type | AC | |
| Load Voltage Range | 24 → 690V ac | |
| Maximum Turn On Time | 10ms | |
| Series | SO8 | |
| Dimensions | 45 x 58.5 x 30mm | |
| Operating Temperature Range | -40 → +100°C | |
| Maximum Operating Temperature | +100°C | |
| Standards Met | CE | |
| Length | 45mm | |
| Depth | 58.5mm | |
| Special Features | Zero Cross with Low Zero-Crossing Level, IP20 Protection, Control Status LED, IP20 Protection | |
| Minimum Operating Temperature | -40°C | |
| Height | 30mm | |
| Select all | ||
|---|---|---|
Brand Celduc | ||
Maximum Load Current 50 A | ||
Mounting Type Panel Mount | ||
Maximum Load Voltage 690 V ac | ||
Minimum Load Voltage 24 V ac | ||
Minimum Control Voltage 20V ac/dc | ||
Maximum Control Voltage 265V ac/dc | ||
Switching Type Zero Cross | ||
Control Voltage Range 20 → 265 V ac/dc | ||
Range SO8 | ||
Number of Poles 1 | ||
Terminal Type Screw | ||
Output Device Thyristor | ||
Relay Type AC | ||
Load Voltage Range 24 → 690V ac | ||
Maximum Turn On Time 10ms | ||
Series SO8 | ||
Dimensions 45 x 58.5 x 30mm | ||
Operating Temperature Range -40 → +100°C | ||
Maximum Operating Temperature +100°C | ||
Standards Met CE | ||
Length 45mm | ||
Depth 58.5mm | ||
Special Features Zero Cross with Low Zero-Crossing Level, IP20 Protection, Control Status LED, IP20 Protection | ||
Minimum Operating Temperature -40°C | ||
Height 30mm | ||
- COO (Country of Origin):
- FR
Single-phase solid state relays, SO8 series
Synchronous solid state relay suited to most loads.
Voltage protection for input (transil) as well as output (VDR) for high immunity to interference.
Wide control range: 3 → 32 Vdc with regulated control current.
Green LED input display.
Solid state relays must be mounted on a heatsink.
Voltage protection for input (transil) as well as output (VDR) for high immunity to interference.
Wide control range: 3 → 32 Vdc with regulated control current.
Green LED input display.
Solid state relays must be mounted on a heatsink.
Standards
EN60947-4-3 and EN60950
Instantaneous Switching
Note
Temperature can affect current rating; please consult the data sheet for potential derating.
