Celduc SO7 Series Solid State Relay, 95 A Load, Panel Mount, 510 V ac Load, 32 V dc Control
- RS Stock No.:
- 917-4787
- Mfr. Part No.:
- SO768090
- Brand:
- Celduc
- RS Stock No.:
- 917-4787
- Mfr. Part No.:
- SO768090
- Brand:
- Celduc
Select all | Attribute | Value |
|---|---|---|
| Brand | Celduc | |
| Maximum Load Current | 95 A | |
| Mounting Type | Panel Mount | |
| Maximum Load Voltage | 510 V ac | |
| Minimum Load Voltage | 25 V ac | |
| Minimum Control Voltage | 3.5 V dc | |
| Maximum Control Voltage | 32 V dc | |
| Switching Type | Random | |
| Control Voltage Range | 3.5 → 32 V dc | |
| Range | SO7 | |
| Minimum Load Current | 5 mA | |
| Number of Poles | 1 | |
| Terminal Type | Screw | |
| Output Device | Thyristor | |
| Relay Type | AC | |
| Load Voltage Range | 25 → 510V ac | |
| Series | SO7 | |
| Maximum Turn On Time | 0.1ms | |
| Dimensions | 45 x 58.5 x 30mm | |
| Standards Met | CE Certified, cULus Recognized | |
| Depth | 58.5mm | |
| Maximum Operating Temperature | +100°C | |
| Special Features | Over-Voltage Protection, Green LED Visualization on The Input, IP20 Protection by Removable Flaps on Terminals with Optional Labels | |
| Minimum Operating Temperature | -40°C | |
| Operating Temperature Range | -40 → +100°C | |
| Length | 45mm | |
| Height | 30mm | |
| Off State Leakage Current | 5 mA | |
| Select all | ||
|---|---|---|
Brand Celduc | ||
Maximum Load Current 95 A | ||
Mounting Type Panel Mount | ||
Maximum Load Voltage 510 V ac | ||
Minimum Load Voltage 25 V ac | ||
Minimum Control Voltage 3.5 V dc | ||
Maximum Control Voltage 32 V dc | ||
Switching Type Random | ||
Control Voltage Range 3.5 → 32 V dc | ||
Range SO7 | ||
Minimum Load Current 5 mA | ||
Number of Poles 1 | ||
Terminal Type Screw | ||
Output Device Thyristor | ||
Relay Type AC | ||
Load Voltage Range 25 → 510V ac | ||
Series SO7 | ||
Maximum Turn On Time 0.1ms | ||
Dimensions 45 x 58.5 x 30mm | ||
Standards Met CE Certified, cULus Recognized | ||
Depth 58.5mm | ||
Maximum Operating Temperature +100°C | ||
Special Features Over-Voltage Protection, Green LED Visualization on The Input, IP20 Protection by Removable Flaps on Terminals with Optional Labels | ||
Minimum Operating Temperature -40°C | ||
Operating Temperature Range -40 → +100°C | ||
Length 45mm | ||
Height 30mm | ||
Off State Leakage Current 5 mA | ||
- COO (Country of Origin):
- FR
Single-phase solid state relays, SO7 series
Voltage protection for input (transil) as well as output (RC + VDR) for very high immunity to interference.
Wide control range: 3 → 32 Vdc with regulated control current.
Green LED input display.
SO7 products are ideal for controlling highly inductive loads or for use in regulator applications.
Solid state relays must be mounted on a heatsink.
