Sensata / Crydom Solid State Relay, 5 A Load, PCB Mount, 530 V rms Load, 32 V dc Control
- RS Stock No.:
- 738-5553
- Mfr. Part No.:
- CXE380D5R
- Brand:
- Sensata / Crydom
Available to back order for despatch 17/10/2024
Added
Price Each
£21.03
(exc. VAT)
£25.24
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £21.03 |
| 10 - 99 | £20.04 |
| 100 + | £18.57 |
- RS Stock No.:
- 738-5553
- Mfr. Part No.:
- CXE380D5R
- Brand:
- Sensata / Crydom
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- MX
Product Details
CX Series SIL SSR, 5A at 12 to 660Vac
Exceptional surge rating and steady state rating of 5A ac
Models to switch from 48-660Vrms
250A pk 1-cycle surge capability
Input-Output capacitance: 10pF
Zero-cross switching where stated otherwise random-fire
Operating temperature range: -30 to +80°C
Dimensions H33mm x W7.6mm x D43.1mm
Models to switch from 48-660Vrms
250A pk 1-cycle surge capability
Input-Output capacitance: 10pF
Zero-cross switching where stated otherwise random-fire
Operating temperature range: -30 to +80°C
Dimensions H33mm x W7.6mm x D43.1mm
Approvals
UL, CSA, VDE
Approvals
UL; CSA; VDE
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 5 A |
| Mounting Type | PCB Mount |
| Maximum Load Voltage | 530 V rms |
| Minimum Load Voltage | 48 V rms |
| Minimum Control Voltage | 15 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Instantaneous |
| Control Voltage Range | 15 → 32 V dc |
| Minimum Load Current | 5 A rms |
| Terminal Type | Through Hole |
| Contact Configuration | SPST |
| Output Device | SCR |
| Package Style | SIP |
| Load Voltage Range | 48 → 530Vrms |
| Maximum Turn On Time | 0.1ms |
| Dimensions | 43.1 x 7.6 x 25.4mm |
| Depth | 7.6mm |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -30°C |
| Operating Temperature Range | -30 → +80°C |
| Length | 43.1mm |
| Off State Leakage Current | 0.1mA rms |
| Height | 25.4mm |
