Banner TL50BL Series Green, Red, Yellow Beacon Tower, 3 Lights, 12 → 30 V dc, Versatile Mount
- RS Stock No.:
- 865-5083
- Mfr. Part No.:
- TL50BLGY1R2Q
- Brand:
- Banner
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 865-5083
- Mfr. Part No.:
- TL50BLGY1R2Q
- Brand:
- Banner
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Banner | |
| Series | TL50BL | |
| Number of Light Elements | 3 | |
| Lens Colour | Green, Red, Yellow | |
| Bulb Type | LED | |
| Light Effect | Flashing, Rotating | |
| Sounder Component | No Sounder Component | |
| Multifunction | Yes | |
| Mounting Style | Versatile Mount | |
| Height | 97.8mm | |
| Base Diameter | 50mm | |
| Connection Type | Integral Quick Disconnect | |
| Supply Voltage | 12 → 30 V dc | |
| Maximum Temperature | +50°C | |
| Current Consumption | 125 mA dc, 80 mA ac | |
| Minimum Temperature | -40°C | |
| Housing Colour | Black | |
Select all | ||
|---|---|---|
Brand Banner | ||
Series TL50BL | ||
Number of Light Elements 3 | ||
Lens Colour Green, Red, Yellow | ||
Bulb Type LED | ||
Light Effect Flashing, Rotating | ||
Sounder Component No Sounder Component | ||
Multifunction Yes | ||
Mounting Style Versatile Mount | ||
Height 97.8mm | ||
Base Diameter 50mm | ||
Connection Type Integral Quick Disconnect | ||
Supply Voltage 12 → 30 V dc | ||
Maximum Temperature +50°C | ||
Current Consumption 125 mA dc, 80 mA ac | ||
Minimum Temperature -40°C | ||
Housing Colour Black | ||
- COO (Country of Origin):
- US
Banner TL50 EZ-LIGHT Signal tower
Banner TL50 EZ-LIGHT beacon signal towers are extremely rugged and built for use in the toughest industrial environments. TL50 LED signal towers are available with a wide range of colour lights and a choice of 150mm pigtails, 2m cable or 4-pin euro quick disconnect connector.
Rugged, cost-effective and easy-to-install multi segment indicators
Illuminated segments provide easy-to-see operator guidance and indication of equipment status
Compact size
12 to 30 V dc or 24 V ac operation
No assembly required
Illuminated segments provide easy-to-see operator guidance and indication of equipment status
Compact size
12 to 30 V dc or 24 V ac operation
No assembly required
