RS PRO PCB Mount Signal Relay, 24V dc Coil, 3A Switching Current, DPDT
- RS Stock No.:
- 800-4514
- Brand:
- RS PRO
- RS Stock No.:
- 800-4514
- Brand:
- RS PRO
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Coil Voltage | 24V dc | |
| Contact Configuration | DPDT | |
| Mounting Type | PCB Mount | |
| Maximum Switching Current AC | 3 A | |
| Maximum Switching Current DC | 3 A | |
| Maximum Switching Voltage AC | 250V | |
| Maximum Switching Voltage DC | 220V | |
| Series | G5V | |
| Maximum Switching Power DC | 90 W | |
| Latching | No | |
| Length | 20.5mm | |
| Depth | 10.1mm | |
| Height | 10.6mm | |
| Dimensions | 20 x 10.6 x 10.2mm | |
| Terminal Type | Through Hole | |
| Number of Poles | 2 | |
| Switching Current | 3A | |
| Application | General Purpose | |
| Maximum Switching Power AC | 125VA | |
| Life | 1000000 (Mechanical) Operations, 50000 (Electrical) Operations | |
| Operating Temperature Range | -40 → +85°C | |
| Coil Power | 200mW | |
| Coil Resistance | 2800Ω | |
| Isolation Coil To Contact | 1.5kV rms | |
| Electrical Life | 1000000 Cycles | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
| Features | Wash Tight, Creepage Distance Of 10 mm, 5 mm Pinning | |
| Contact Material | Silver | |
| Standards Met | CQC 13002095174, cULus E133481, RoHS Compliant | |
| Relay Switching Classification | Subminiature DIP Relay | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Coil Voltage 24V dc | ||
Contact Configuration DPDT | ||
Mounting Type PCB Mount | ||
Maximum Switching Current AC 3 A | ||
Maximum Switching Current DC 3 A | ||
Maximum Switching Voltage AC 250V | ||
Maximum Switching Voltage DC 220V | ||
Series G5V | ||
Maximum Switching Power DC 90 W | ||
Latching No | ||
Length 20.5mm | ||
Depth 10.1mm | ||
Height 10.6mm | ||
Dimensions 20 x 10.6 x 10.2mm | ||
Terminal Type Through Hole | ||
Number of Poles 2 | ||
Switching Current 3A | ||
Application General Purpose | ||
Maximum Switching Power AC 125VA | ||
Life 1000000 (Mechanical) Operations, 50000 (Electrical) Operations | ||
Operating Temperature Range -40 → +85°C | ||
Coil Power 200mW | ||
Coil Resistance 2800Ω | ||
Isolation Coil To Contact 1.5kV rms | ||
Electrical Life 1000000 Cycles | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature +85°C | ||
Features Wash Tight, Creepage Distance Of 10 mm, 5 mm Pinning | ||
Contact Material Silver | ||
Standards Met CQC 13002095174, cULus E133481, RoHS Compliant | ||
Relay Switching Classification Subminiature DIP Relay | ||
- COO (Country of Origin):
- CN
Subminiature Dip Relay
Contacts: 2 Form C, DPDT
Fits standard 16 pin IC socket
Epoxy sealed for cleaning and wave soldering
Maximum soldering temperature 270° C for 5 seconds
Approvals
